Operation
3.17 Lock lever
Lock lever (up to serial no. AI00814)
Fig. 136: Lock lever
Lock lever (from serial no. AI00815)
Fig. 137: Lock lever
3-62
Locking the lock lever
Set lever 12 to position A.
The control levers are locked.
Unlocking the lock lever
12
Set lever 12 to position B.
The control levers are unlocked.
Locking the lock lever
Set lever 12 to position A.
The control levers are locked.
12
Unlocking the lock lever
Set lever 12 to position B.
The control levers are unlocked.
WARNING Warning!
Crushing hazard due to unexpected movements of the
machine or attachments!
Can cause serious injury or death.
• Raise the lock lever before leaving the machine.
• Locking the lock lever makes it impossible to perform any functions with the
control and travel levers.
• The boom can still be swiveled if the lock lever is raised.
• The auxiliary hydraulics can still be operated if the lock lever is raised.
