Instructions for assembly and use
4.0.0

Colour function overview (optional LED colour lamp WC4-CL-R)

Point 3 of these operating instructions relates to the LED colour light option (see
Point 1.3.0 of these operating instructions).

4.1.0 COLOUR CODING

The following colour coding is assigned to the digits:
0...........dark, off
1...........red
2...........red, yellow
3...........yellow
4...........yellow, green

4.2.0 SWITCHING ON COLOUR

The Wave.com4 sauna control unit must be connected to the mains.
The symbol (ready for operation) illuminates on the operating unit of the LED colour light.
By pressing the
automatically changes to the last executed operating state (automatic or manual).

4.3.0 AUTOMATIC COLOUR MECHANISM (MODE)

As soon as you switch on the control unit, the
mechanism) symbols illuminate.
The digit in the display shows the active colour (see 3.2.0).
WE DO IT FIRST.
Figure 32: LED colour operating units in the available colours
5............green
6............green, blue
7............blue
8............red, yellow, green, blue
key the control unit for the LED colour light is activated and the control unit
(ready for operation) and (Automatic
37 /228
