Instructions for assembly and use
Operating unit:
The input and display module with a membrane keyboard operating display has a seven segment
display. The operating unit is connected to the base module using RJ10 4/4.
Cleaning of the front film:
Select a cleaning interval adapted to the degree of soiling
4. Disconnect the wave.com4 sauna control system completely from the mains and
switch off all poles
5. Do not remove any component of the Wave.com4 sauna control system
6. Gently wipe the front film with a dry cloth or a soft cloth slightly moistened with
soapy water (see Figure 4).
Do not clean the back and the circuit board behind it yourself under any
circumstances!
In the case of doubt, contact qualified specialists (authorised electronics
specialist).
Figure 21: description of operating unit
WE DO IT FIRST.
7 segment display
Operating elements
Front film
13 /228
