Instructions for assembly and use
3.12.8

Several operating units on the bus

You can in practice connect max. 3 operating units and in theory (Y-adapter RJ12 6/6-
optional: WC4-SL-EXT) 4 operating units to the bus (Port RJ10 4/4).
The component WC4-B-L has 2 RJ10 4/4 sockets and 1 RJ12 6/6 socket.
If you use several operating units, you must assign each operating unit (maximum 3
operating units) a bus address. Address 0 is the standard value.
Each address can be used only once or may not be assigned to multiple operating
units.
The address can be changed as follows:
Unplug the bus/supply cable of the operating unit.
Press and hold the
cable into the relevant port on component WC4-B-L.
You can now see the address assigned to this operating unit flashing.
Change the address with the
used.
Confirm your selection with the
When the aforementioned settings have
ended, the Wave.com4 sauna control unit
must be disconnected from the mains and
reinitialised (address recognition occurs
when the Wave.com4 sauna control unit is
started up).
Sauna and colour light operating units do not have the same address allocation.
They are thus completely independent of one another.
WE DO IT FIRST.
keys on the unplugged operating unit and and meanwhile plug the data
keys (address 0-3 possible) when several operating units are
button.
