Instructions for assembly and use
•
The Port Res.5 Port on the WC4-H-PCB component is a 230V input
•
Both continuous voltage and impulse voltage (230V) can be used (see Point 3.12.5.2
of these operating instructions).
3.12.5.2
Remote start programming
When you select operating modes 4 or 5, you can make additional settings.
Here you can specify to the control unit whether the Wave.com4 sauna control unit should remain
switched on when the remote contact voltage has ceased:
Switch on
Switch off
Confirm your selection either with the
3.12.6
Display: automatic relaying
The operating unit display can be programmed to automatic relaying.
In this mode, the display alternately shows you temperature [° C], time [hours], brightness [%] and
the humidity value [%], insofar as the optionally available components for climate operation of the
Wave.com4 sauna control device are used (see Point 1.3.0 of these operating instructions).
Change to the
Simulaneously pressing the
the automatic relaying of the display of your operating unit
Switch on/off the automatic relaying with the
Confirm your selection either with the
The following setting can also be made:
Where the optional LED components are used (see Point 1.3.0 of these operating
instructions) you can also specify to the Wave.com4 sauna control unit whether the
cabin light should illuminate at the same time as the LED colour lamp or not.
•
Simultaneous operation = ALL
•
Single operation of cabin and LED light = LED
Confirm your selection with the
WE DO IT FIRST.
symbol (light brightness) with the
keys for at least 3 seconds will take you to the settings menu for
(Select = "on")
(Select "off")
or
keys.
or
keys.
or
keys.
or
keys.
key.
31 /228
