9
ADJUSTMENTS
9.7
CUTTING UNIT
Refer to manual 23870G for all Cutting Unit
adjustments.
WARNING
CUTTING CYLINDER TO BOTTOM
BLADE ADJUSTMENT
To ensure the cutting circuit has
no back pressure. The following
procedure should be used.
1.
Stop cutting cylinder rotation
by putting control lever into
the neutral position.
2.
The units should be raised (to
close the diverter valves) then
lowered and the engine
switched off.
The cutting units can now be
rotated freely to assist setting the
cylinder to bottom blade.
GB-40
All manuals and user guides at all-guides.com
SAFETY, OPERATORS & MAINTENANCE MANUAL
RANSOMES COMMANDER 3520
