5 DECALS
5.1 SAFETY DECALS
A903491 Read Operator's Manual.
A903489 Keep a Safe Distance from the
Machine.
A903492 Stay Clear of Hot Surfaces.
A903488 Do Not Open or Remove Safety
Shields While the Engine is Running.
A903494 Caution Rotating Blades.
A903493 Avoid Fluid Escaping Under Pressure.
Consult Technical Manual for Service
Procedures.
A903490 Do Not Remove Safety Shields While
Engine is Running.
A911410 Danger of Explosion if the Battery
Terminals are Short Circuited.
A911416 Maximum permissible working slope.
A911423 Caution, Disconnect Reel Support
Springs Before Removing Reels
A911434 Caution Diesel Fuel
5.2 INSTRUCTION DECALS
1 Cutting cylinder circuit pressure
2 Horn
3 Weight Transfer
4 Cutting unit lift levers
5 Cutting cylinder forward-neutral-reverse
6 Parking brake
7 Water to antifreeze mix
8 Test ports
9 Diesel fuel
10 Transport/Cutting speed select
11 Slinging point
12 Pointer
13 Cutting unit drive switch
14 Ignition switch
15 Forward cylinder rotation
16 Reverse 4WD
17 Reverse cylinder rotation
18 Single Unit Cutting
19 Weight transfer
20 Forward/Reverse traction pedal
21 Maximum sound power level
22 Hydraulic Filter
