LUBRICATION AND MAINTENANCE
MAINTENANCE
8.5 ENGINE : Every 100 hrs
Air cleaner (A)
1.
As the element (A) of the air cleaner
employed on this engine is a dry type, never
apply oil to it.
2.
Open the evacuator valve once a week under
ordinary conditions-or daily when used in a
dusty place-to get rid of large particles of dust
and dirt.
3.
Avoid touching the element except when
cleaning.
4.
When dry dust adheres to the element, blow
compressed air from the inside turning the
element. Pressure of compressed air must
be under 7kgf/cm
2
(100psi)
5.
When carbon or oil adheres to the element,
soak the element in detergent for 30 minutes
then wash it several times in water, rinse with
clean water and dry it naturally. After the
element is fully dried, inspect inside of the
element with a light and check if it is
damaged or not. (referring to the instructions
on the label attached to the element.)
NOTE: Make sure the wing-head bolt for the
element is tight enough. If it is loose, dust
and dirt may be sucked into the engine,
causing premature engine wear with
resulting loss of power.
8.6 ENGINE : Every 400 hrs
Replace In-line fuel filter (A)
Changing main fuel filter (B)
1.
Unscrew locking ring and remove glass bowl
and filter element. Discard filter element.
2.
Place new filter element in filter bowl locating
on spring. Position bowl against gasket in
filter head and fit locking ring.
3.
Vent the fuel system.
All manuals and user guides at all-guides.com
SAFETY, OPERATORS & MAINTENANCE MANUAL
RANSOMES COMMANDER 3520
GB-35
