11 SCHEMATICS
11.7 ELECTRICAL KEY
KEY TO FUSE & RELAY DIAGRAM
Rating
1. Fuse 2 Amp
2. Fuse 10 Amp
3. Fuse 20 Amp
4. Fuse 10 Amp
5. Fuse 10 Amp
6. Fuse 15 Amp
7. Fuse 15 Amp
8. Fuse 10 Amp
9. Fuse 10 Amp
10. Fuse 2 Amp
11. Fuse 10 Amp
12. Fuse 5 Amp
13. Fuse 10 Amp
14. Fuse 10 Amp
15. Fuse 5 Amp
16. Fuse 5 Amp
17. Relay
18. Relay
19. Relay
20. Relay
21. Relay
22. Relay
23. Diode Bridge
24. Main Fuse
25. Stop Solenoid Timer
