OVERViEW OF MiTRE SAW

1
2
3
4
5
6
7
8
9
10
11
12
1. Dust Bag *
2. On/Off Trigger Switch
3. Blade Guard Release Trigger
(Eu Models)/Lock-Off Button
(Canadian Model)
4. Extraction Port
5. Slide Carriage Locking Screw
6. Carriage Slides
7. Laser Guide
8. Bevel Lock Lever
9. Hold Down Clamp
10. Sliding Fence
11. Workpiece Support *
12. Mounting Hole (X4)
13. Arbor Lock Button
14. Head Latching Pin
15. Depth Gauge
16. Handle
17. Motor
18. Upper Blade Guard
19. Blade
(Housed Inside Blade Guard)
20. Retractable Lower
Blade Guard
14
www.evolutionpowertools.com
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
21. Repeat End Stop *
22. Base
23. Table Top
24. Rotary Table
25. Mitre Angle Scale
26. Mitre Locking Handle
27. Positive Stop Locking Lever
*
Supplied as original equipment
on the RAGE3+ and RAGE3-S+
and RAGE3-S300.
