10 Maintenance and cleaning

10 Maintenance and cleaning
Scheduled maintenance and cleaning are prerequisites for a long service life and trouble-free operation.
DANGER
Risk of injury due to unexpected start
The following instructions must be adhered to during all maintenance, servicing, assembly, disassembly and repair work:
• Switch off the power source.
• Disconnect all electrical connections.
DANGER
Risk of burns
Risk of burns due to hot surfaces.
• Wear protective gloves.
DANGER
Electric shock
Dangerous voltage due to defective cables.
• Check all live cables and connections for proper installation and damage.
• Replace any damaged, deformed or worn parts.
NOTICE
• Always wear your personal protective equipment when performing maintenance and cleaning work.
10.1 Cleaning the linear unit
NOTICE
• Use a cloth to remove heavy soiling weekly.
• Do NOT use compressed air.
10.2 Servicing the linear unit
NOTICE
• The cleaning unit is greased before delivery of the system.
• All ball bearings are greased for the entire service life and do not need to be periodically greased under normal
conditions.
10.2.1 Greasing the linear guidance system and ball nut
NOTICE
• To grease the linear unit, use only a lubricant WITHOUT solids.
• Recommended lubricant: Lubcon TURMOGREASE LC 802 EP
Fig. 24 Lubrication holes
