Card access only
Present card
PIN and card access
Present card
Card access only is selected
Press the # key to open the door.
Then hold your access card over the
symbol on the keypad.
The green LED (6) will turn on for 3 seconds
to confirm that the lock has been opened.
The relay controls the connected switching
device, e.g. door opener. It automatical-
ly closes again after the preset time has
elapsed (approx. 5 seconds).
PIN and card access is selected
Press the # key to open the door.
Then hold your access card over the
bol on the keypad.
Type in the user PIN code (in the example,
the user PIN code is 83221) and press # to
confirm your entry.
The green LED (6) will turn on for 3 seconds
to confirm that the lock has been opened. The
relay opens the connected switching device,
e.g. door opener. It automatically closes
again after the preset time of 5 seconds has
elapsed.
sym-
