English
1
Important notes................................................................... 3
2
Explanation of symbols......................................................... 3
3
Supplemental directives........................................................3
4
Safety instructions................................................................ 3
5
Target groups...................................................................... 3
6
Intended use....................................................................... 3
7
Technical description............................................................3
8
Installation......................................................................... 10
9
Operation..........................................................................12
10
Disposal............................................................................ 14
11
Warranty............................................................................ 14
1 Important notes
Please read these instructions carefully and follow all instructions, guidelines, and warnings included in this product manual in order
to ensure that you install, use, and maintain the product properly at all times. These instructions MUST stay with this product.
By using the product, you hereby confirm that you have read all instructions, guidelines, and warnings carefully and that you
understand and agree to abide by the terms and conditions as set forth herein. You agree to use this product only for the intended
purpose and application and in accordance with the instructions, guidelines, and warnings as set forth in this product manual as
well as in accordance with all applicable laws and regulations. A failure to read and follow the instructions and warnings set forth
herein may result in an injury to yourself and others, damage to your product or damage to other property in the vicinity. This product
For up-to-date product information, please visit documents.dometic.com.
manual, including the instructions, guidelines, and warnings, and related documentation, may be subject to changes and updates.
2 Explanation of symbols
A signal word will identify safety messages and property damage messages, and also
will indicate the degree or level of hazard seriousness.
WARNING!
Indicates a hazardous situation that, if not avoided, could result in death or
serious injury.
NOTE Supplementary information for operating the product.
3 Supplemental directives
To reduce the risk of accidents and injuries, please observe the following directives
before proceeding to install or operate this appliance:
• Read and follow all safety information and instructions.
• Read and understand these instructions before installing or operating this product.
The installation must comply with all applicable local or national codes, including the
latest edition of the following standards:
USA
• American Boat and Yacht Council (ABYC) E-11 AC and DC Electrical Systems on Boats
• ANSI/NFPA70, National Electrical Code (NEC)
Canada
CSA C22.1 Parts I and II, Canadian Electrical Code
4 Safety instructions
WARNING! Electrical shock, fire, and/ or explosion hazard
Modification can be extremely hazardous.
Use only Dometic replacement parts and components that are specifically
approved for use with the appliance.
Avoid improper installation, change, alterations, service, or maintenance of
the appliance.
Do not change this product in any way.
Be careful when diagnosing and/or adjusting components on a powered
unit. Disconnect all remote maintenance electric power supplies before
servicing.
5 Target groups
The mechanical and electrical installation and setup of the device must
be performed by a qualified technician who has demonstrated skill and
knowledge related to the construction and operation of marine equipment
and installations, and who is familiar with the applicable regulations of the
country in which the equipment is to be installed and/or used, and has
received safety training to identify and avoid the hazards involved.
6 Intended use
The Basic Chiller Control is designed to control the operation of one or more marine
chillers.
This product is only suitable for the intended purpose and application in accordance
with these instructions.
This manual provides information that is necessary for proper installation and/or
operation of the product. Poor installation and/or improper operation or maintenance
will result in unsatisfactory performance and a possible failure.
The manufacturer accepts no liability for any injury or damage to the product resulting
from:
• Incorrect installation, assembly or connection, including excess voltage
• Incorrect maintenance or use of spare parts other than original spare parts provided
by the manufacturer
• Alterations to the product without express permission from the manufacturer
• Use for purposes other than those described in this manual
Dometic reserves the right to change product appearance and product specifications.
7 Technical description
7.1
Features
The product uses temperature differential and hysteresis to manage the capacity of
the chiller in single or multistage application. The controller has a PGD1 or PGD1 LCD
display.
The user can select between Cool, Heat, or Electric Heat (EH) mode
operation in single or multistage configuration.
The system is internally grounded with isolation between inputs and outputs.
Additionally, the output relays offer double isolation so that different voltages can be
used for groups of relays.
The system uses various sensor types for measuring analog temperatures and pressures.
For temperature measurements, the system uses NTC type 10 kΩ @ 77°F (25°C)
thermistors. Pressure transducers are ratiometric 0 psi (0 bar) ... 650 psi (44.82 bar)
(45 bar) range for both suction and discharge monitoring.
Available options:
• Compressor current monitoring
• Pump current monitoring (SW and CW)
• Condenser freeze protection
• Electric heat
• EEV control
• Pressure transducers
• Load shedding input signal
EN
3
