Product information

°C °C
20 14772 45 5523
25 12000 50 4608
30 9786 55 3856
35 8047 60 3243
40 6653 65 2744
Table 3 Temperature sensor measurements (TS2 - TS6, TS8 - TS20)

°C °C
– 30 364900 25 20000
– 20 198400 30 16090
– 10 112400 35 12800
0 66050 40 10610
5 50000 50 7166
10 40030 60 4943
15 32000 70 3478
20 25030 75 2900
Table 4 Collector temperature sensor measurements (TS1 / TS7)
2.9 Additional accessories
For detailed information about suitable accessories, refer to the
catalogue or Internet page of the manufacturer.
• For solar thermal system 1:
– Solar pump; connection to PS1
– electronically regulated pump (pulse width modulation or
0-10 V); connection to PS1 and OS1
– Temperature sensor (1st collector array); connection to TS1
(scope of delivery)
– Temperature sensor at the bottom of the 1st cylinder; connection
to TS2 (scope of delivery)
• Additionally for central heating backup (A) (
– 3-way valve; connection to VS1/PS2/PS3
– Temperature sensor in the middle of the 1st cylinder; connected
to TS3
– Temperature sensor at the return; connection to TS4
• Additionally for 2nd cylinder/swimming pool with valve (B):
– 3-way valve; connection to VS2
– Temperature sensor at the bottom of the 2nd cylinder; connection
to TS5
• Additionally for 2nd cylinder/swimming pool with pump (C):
– 2nd solar pump; connection to PS4
– Temperature sensor at the bottom of the 2nd cylinder; connection
to TS5
– 2nd electronically regulated pump (pulse width modulation or
0-10 V); connection to OS2
• Additionally for central heating backup cyl. 2 (D) (
– 3-way valve; connection to VS1/PS2/PS3
– Temperature sensor in the middle of the 2st cylinder; connected
to TS3
– Temperature sensor at the return; connection to TS4
• Additionally for external heat exchanger at the 1st or 2nd cylinder
(E, F or Q):
– Heat exchanger pump; connection to PS5
– Temperature sensor on heat exchanger; connection to TS6
• Additionally for 2nd collector array (G):
– 2nd solar pump; connection to PS4
– Temperature sensor (2st collector array); connection to TS7
– 2nd electronically regulated pump (pulse width modulation or
0-10 V); connection to OS2
28
 
°C °C
70 2332 95
75 1990 100
80 1704 –
85 1464 –
90 1262 –
 
°C °C
80 2492 150
90 1816 160
95 1500 170
100 1344 180
110 1009 190
120 768 200
130 592 –
140 461 –
):
):
• Additionally for return temperature control (H) (

– Mixer; connection to VS1/PS2/PS3
1093
– Temperature sensor in the middle of the 1st cylinder; connected
950
to TS3
–
– Temperature sensor at the return; connection to TS4
–
– Temperature sensor at the cylinder flow (after the mixer);
– connection to TS8
• Additionally for transfer system (I):
– cylinder primary pump; connection to PS5

• Additionally for transfer system with heat exchanger (J):
364
– cylinder primary pump; connection to PS4
290
– Temperature sensor at the top of the 1st cylinder; connection to
233
TS7
189 – Temperature sensor at the bottom of the 2nd cylinder; connection
to TS8
155
– Temperature sensor at the top of the 3rd cylinder; connection to
127
TS6 (only if no heat source other than the solar system is installed)
–
• Additionally for thermal disinfection (K):
–
– Thermal disinfection pump; connection to PS5
• Additionally for heat meter (L):
– Temperature sensor in flow to solar collector; connection to IS2
– Temperature sensor in return from solar collector; connection to
IS1
– Water meter; connection to IS1
• Additionally for temperature differential controller (M):
– Heat source temperature sensor; connection at MS 100 to TS2
– Heat sink temperature sensor; connection at MS 100 to TS3
– Assembly (pump or valve) to be controlled; connection at MS 100
to VS1/PS2/PS3 with output signal at terminal 75; terminal 74
not assigned
• Additionally for 3rd cylinder/swimming pool with valve (N):
– 3-way valve; connection to PS4
– Temperature sensor at the bottom of cylinder 3; connection to TS7
• For transfer system 3:
– Temperature sensor at top of 2nd cylinder (scope of delivery)
– Temperature sensor at top of 1st cylinder
– Temperature sensor at bottom of 1st cylinder
– Pump for thermal disinfection (optional)
• For primary store system 4:
– Temperature sensor at top of 1nd cylinder (scope of delivery)
– Temperature sensor at bottom of 1st cylinder
– Pump for DHW circulation (optional)
• For primary store system 5:
– Temperature sensor at top of 1nd cylinder (scope of delivery)
– Temperature sensor at bottom of 1st cylinder
– Pump for DHW circulation (optional)
– Header sensor set
Installation of additional accessories
▶ Install the additional accessories in accordance with legal regulations
and the instructions supplied.
2.10 Cleaning and care
▶ If required, wipe the casing with a damp cloth. Never use aggressive
or acidic cleaning agents for this.
):
