7.2.2) Level one programming (ON-OFF functions)
Level 1 functions are all factory set to "OFF". However, they can be changed at any time as shown in Table 6. Follow the procedure carefully,
as there is a maximum time of 10 seconds between pressing one key and another. If a longer period of time lapses, the procedure will finish
automatically and memorize the modifications made up to that stage.
Table 6: changing ON-OFF functions
1. Press the key [Set] and hold it down (approx. 3 s)
2. Release the [Set] key when L1 LED starts flashing
3. Press keys [s] or [t] to move the flashing LED onto the LED representing
the function which is to be changed
4. Press the [Set] key to change the state of the
function (short flashing = OFF; long flashing = ON)
5. Wait 10 seconds before leaving the programme to allow the maximum time to lapse.
Note: Points 3 and 4 can be repeated during the same programming phases in order to set other functions to ON or OFF
7.2.3 Level two functions (adjustable parameters)
Table 7: programmable function list: level two
Input LED Parameter
L1 Pause
Time
L2 Step-by-step
L3 Motor
speed
L4
Open Gate Indi-
cator Output
L5 Motor
force
LED (level) Value
L1 5 seconds
L2 15 seconds
L3 30 seconds
L4 45 seconds
L5 60 seconds
L6 80 seconds
L7 120 seconds
L8 180 seconds
L1 Open - stop - close - stop
L2 Open - stop - close - open
L3 Open - close - open - close
L4 Condominium operation
L5 Condominium operation 2 (more than 2" causes stop)
L6 Step-by-Step 2 (less than 2" causes partial opening)
L7 Man present
L8 "Semiautomatic" opening,
"Man present" closing
L1 Very slow
L2 Slow
L3 Medium
L4 Fast
L5 Very fast
L6 Extremely Fast
L7 Opens "Fast"; closes "slow"
L8 Opens "Extremely Fast" Closes "Fast"
L1 Open Gate Indicator Function
L2 On if leaf closed
L3 On if leaf open
L4 Active with 2nd radio output
L5 Active with 3rd radio output
L6 Active with 4th radio output
L7 Maintenance indicator
L8 Electric lock
L1 Super light gate
L2 "Very light" gate
L3 "Light" gate
L4 "Average" gate
L5 "Average-heavy" gate
L6 "Heavy" gate
L7 "Very heavy" gate
L8 "Super heavy" gate
Example
SET
L1
or
SET
Description
Adjusts the pause time, namely the time
which lapses before automatic closure.
This will only have an effect if automatic
closing is active.
Manages the sequence of controls associ-
ated to the Step-by-Step input or to the
1st radio command.
Adjusts the speed of the motor during nor-
mal travel.
MODEL 250HS / 500HS: factory value =
L5
Adjusts the function associated with the
S.C.A. output (whatever the associated
function may be, the output supplies a
voltage of 24V –30 +50% with a maximum
power of 4W when active).
Adjusts the system which controls the
motor force in order to adapt it to the
weight of the gate. The force control sys-
tem also measures the ambient tempera-
ture, automatically increasing the force in
the event of particularly low temperatures.
3s
SET
10s
