To program on the separate programming track, either connect a stretch of track which is electrically
isolated from the rest of the system to the track output on the booster or switch off the rest of the system
with a switch before programming.
Example: To program the locomotive address = CV1 to value 4:
Input
+
You can also program new values for CV 2, 3, 4 and 5 as shown in this example. To do so, you simply press the
"Menu" key together with the „function key" with the number corresponding to the CV and then proceed as in
the above example.
If you set value "8" in CV8 (no other value can be entered), all the decoder's CVs are reset to the factory set-
ting.
7.

Short circuit and overload

If a short circuit or an overload occurs on the system, the multiMAUS indicates
this using two flashing symbols on the display screen: a streak of lightning and
the STOP symbol At the same time the voltage supply to the system is shut off.
If there is a short circuit, e.g. because of a derailed coach or train, eliminate the
fault.
Press the "STOP" key once to switch the system back on with a delay of ap-
proximately one second.
If the fault is not a short circuit, the cause may be an overload of the system due to the operation of several
locomotives at a time. If this occurs frequently, the power supply to your system is insufficient. Connect an
additional booster (section 3 "T
normal transformer connected directly to the power supply as this will destroy the multiMAUS and booster.
Display message
Press the "MENU" key and "function key" 1 to-
gether.
The display screen briefly shows the selected CV
and then switches immediately to display the ficti-
The displayed fictitious suggested value is easily
overwritten by pressing one of the "function keys".
The cursor flashes.
Confirm by pressing "OK". After the last display
"PROG" the multiMAUS returns to drive mode.
Note: If you have changed CV1 for a locomotive,
check whether the specification of the locomotive's
address in the library matches.
B ", page 55). You must not under any circumstances use a
he 1 07 6 5 oosTer
Comment
tious suggested value.
