Roco multiMAUS Manuel page 35

Light / OK key
in combination with
Shift key
Stop key
in combination with
Shift key
Locomotive / turnout key
in combination with
Shift key
...
Function keys
in combination with
Shift key
Shift key
menu key
in combination with
Shift key
in combination with
...
Function keys
Switch the light on or off (in drive mode)
▪
Confirm inputs (in turnout mode and in the menus)
▪
Call up desired menu level or menu items
▪
In locomotive address mode:
Select another locomotive by directly inputting an locomotive address
▪
In drive mode:
Emergency stop on entire system
▪
In menu mode:
Return from the respective menu level
▪
In drive mode:
Selective emergency stop for the locomotive selected and displayed
▪
Switch between locomotive and turnout mode
▪
Switch between library and locomotive address mode
▪
In drive mode:
Switch the locomotive functions F1 – F10 on or off directly. The locomotive func-
▪
tions F11 – F20 are switched using keys 1 – 10 together with the shift key. The acti-
vated locomotive functions can be seen on the display screen.
In menu mode:
Input a locomotive name (alphanumerical) in the library
▪
Fast access to the menu items out of the menu level
▪
In turnout mode:
Input turnout number directly
▪
Switch locomotive functions F11 – F20 on or off. You can check the activated
▪
functions by pressing the "shift" key.
In turnout mode:
Call up to 10 saved turnouts (turnout shortcut keys)
▪
In drive mode:
Check the activated functions F11 – F20
▪
Switch to menu mode (press and hold for approximately 5 seconds)
▪
Return directly from all menu levels to locomotive / turnout mode
▪
Switch to menu mode
▪
Return directly from all menu levels to locomotive / turnout mode
▪
In library or locomotive address mode:
Quick-program CVs 1 – 5 and 8 ("MENU" key must be pressed first)
▪
in turnout mode:
Quick call to saved turnouts (turnout shortcut keys)
▪
