INSTRUCTIONS FOR USE
Prone Position Equipment
This picture shows a
•
common prone position
setup.
The final responsibility for
•
patient care with respect
to this device remains
with the attending
physician.
See each component IFU
•
for installation and
operation.
Patient Support Devices
•
Wingsets
•
Head Positioner
•
•
•
OR Table Pad
•
Armboards
•
•
•
By using different thickness pads the legs
•
can be brought up or down for better
pressure management.
When using intra-operative flex, re-
adjust the head positioner to insure
chin and face are properly supported.
Refer to C-Prone or C-Flex IFU for
adjustment information.
Document Number: 80028177
Version E
C-Flex
C-Prone
Prone Armboard
(shown/optional)
Easy Armboard
(optional)
