THE MITRE LOCKING KNOB (14 - on machine overview)
The threaded spigot of the Mitre Locking Knob slides
through a hole in the front of the Mitre Locking Handle
(Fig. 8) and then screws into an internally threaded boss
located in the base of the machine.

INSERTING THE CARRIAGE SLIDE

IMPORTANT: If for any reason (transit damage, unpacking
error, operator mistake, etc.) the locating lugs at the tip
of the carriage slide arms have been 'tripped' , the sliding
carriage cannot be fitted into the bevel neck or onto the
cutting head. The locating lugs (Fig. 9) must be reset, if
either or both have been 'tripped' prematurely.
Fig. 5
Fig. 6
Fig. 8
Fig. 9
