MACHINE OVERVIEW

2
5
6
8
7
17 18
1. CUTTING HANDLE
2. REAR CARRY HANDLE
3. SLIDE LOCKING SCREW
4. DEPTH STOP
5. 3 PC HOLD DOWN CLAMP
6. SLIDING FENCE
7. MACHINE TABLE EXTENSIONS
8. MOUNTING HOLE (X4)
9. BLADE ROTATION INDICATION ARROW
10. UPPER BLADE GUARD
1
19
3
4
20
11. BLADE
12. LOWER BLADE GUARD
13. BEVEL ANGLE SCALE
14. MITRE HANDLE LOCKING KNOB
15. POSITIVE STOP LOCKING LEVER
16. MITRE ANGLE SCALE
17. DUST PORT ADAPTER
18. DUST BAG
19. LED BLADE GUIDE LINE
20. ROTARY TABLE
12
