10.3.8 Settings dialogues
Installation and operating instructions Wilo-Stratos GIGA2.0-I, Wilo-Stratos GIGA2.0-D
Commissioning
Settings
Set auto control
Settings assistant, setpoints, options
Manual operation
Manual override
Double pump operation
Set double pump
External interfaces
Analogue, digital, SSM, SBM
Fig. 34: Settings menu
NOTICE
1
There is an arrow above or below the visible menu items if there are more than
four sub-menu items. Turn the operating button in the corresponding direction to
open the sub-menu items on the display.
1
An arrow above or below a menu area indicates that additional sub-menu items are
available in this area. These sub-menu items are accessible by turning
ating button.
2
An arrow towards the right in a sub-menu item indicates that another sub-menu is
available. Press the operating button to open this sub-menu.
If there is no arrow to the right, press the operating button to open a settings dialogue.
3
A note above the "Context" button shows specific functions of the "Context"
menu. Press the "Context" menu button
NOTICE
Briefly press the "Back" button
Briefly press the "Back" button
screen". If there is an error, press the "Back" button
("Error messages" section).
If there is an error, press and hold the "Back" button
tings dialogue or from any menu level to return to the "Home screen" or error dis-
play.
Settings dialogues have been highlighted with a yellow frame and show the current
setting.
Turn the operating button to the right or left to adjust the highlighted setting.
Press the operating button to confirm the new setting. The focus returns to the menu
you opened.
If you do not turn the operating button before pressing, the previous setting remains
unchanged.
One or more parameters can be set in the settings dialogues.
ƒ
If only one parameter can be set, the focus returns to the menu you opened after
having confirmed the parameter value (pressing the operating button).
ƒ
If several parameters can be set, the focus changes to the next parameter after
having confirmed a parameter value.
If you confirm the last parameter in the settings dialogue, the focus returns to the
menu you opened.
Press the "Back" button
previously changed value will be discarded because it had not been confirmed.
Overriding
auto control via
manual intervention.
2
1
to open the "Context" menu.
in a sub-menu to return to the previous menu.
in the main menu to return to the "Home
to return to the error display
(> 1 second) from any set-
to return the focus to the previous parameter. The
en
3
the oper-
