10.3.3

Initial settings menu

10.3.4 Main menu
180
Commissioning
ƒ
Turn : menu selection and parameter setting.
ƒ
Press : activation of menus or confirming settings.
Press the "Back" button
change the focus back to the previous focus. Consequently, the focus moves one level
further up in the structure or to a previous setting.
Pressing the "Back" button
confirming the changed value returns the focus to the previous focus. The adjusted
value will be discarded. The previous value remains unchanged.
If the "Back" button is pressed for more than 2 seconds, the "Home screen" opens
and the pump can be operated from the main menu.
NOTICE
If there are no warning or error messages, the display on the electronic module will
switch off 2 minutes after the last time it was operated.
• If the operating button is pressed or turned again within 7 minutes, the previously
exited menu will appear. You can continue to configure settings.
• If the operating button is not pressed or turned for more than 7 minutes, any un-
confirmed settings will be lost. Pressing the button again opens the Home screen on
the display and the pump can be operated from the main menu.
The settings menu will appear in the display during initial commissioning of the pump.
NOTICE
The factory setting for variant ... R1 (without differential pressure sensor as de-
livered) is the basic control mode "Constant speed". The factory setting mentioned
below refers to the variant with a differential pressure sensor fitted in the factory.
WELCOME - WILO-STRATOS GIGA2.0
Start with factory settings
Pump operates for radiator
First settings
for commissioning
Fig. 31: Initial settings menu
ƒ
You can exit the initial settings menu by activating "Start with factory settings"
menu. The display changes to the main menu. The pump continues to run using the
factory settings.
ƒ
In the "Initial settings" menu, language, units and applications can be selected and
adjusted. The chosen initial settings are confirmed by activating "Finish initial set-
tings". The display changes to the main menu.
Quit the Initial settings menu to open the Home screen on the display and operate it
from the main menu.
("Description of operating elements" [} 178] table) to
after having changed a setting (yellow focus) without
The pump has been
successfully installed.
Pump is currently running in
factory setting:
Application:
Radiator
Control mode:
Dynamic Adapt plus
WILO SE 2021-12
