Mounting the glassware
Note: Observe "Drawings for mounting the glassware" on page 230.
Item Designation
RV 10.1 non-coated
RV 10.10 coated
1 Receiving flask
2 Clamp (stainless steel)
4 Stopcock
5 Pipe tube
6 Condenser 1 Vertical condenser
7 Connection 1 Vacuum connection
8 Clamp (plastic)
10 Evaporation flask 1000 ml
11 Ball joint clamp RV 05.10
12 Screw joint cap
13 Hose connection
14 Manifold
15 Cover cap
16 Cartridge
17 Ring, slotted
18 Washer
19 O-ring
20 Plug, high vacuum
Note:
The PTFE tube (5) with the washer (18) can be mounted optionally on the vertical glass sets.
It serves for filling the evaporator flask when there is a vacuum in the glass set.
Solvent can be sucked through the PTFE tube into the evaporator flask by opening the stopcock (4).
Mounting the washer
Note: Pay attention to the correct position of the washer.
Removing the condenser
• Use the ring spanner provided to loosen union nuts that are
tightly fitted.
• Loosen the union nut by turning counterclockwise.
• Remove the Velcro .
®
Note: Ring spanner is only used for removing the condenser,
while fixing the condenser please use hands.
38
RV 10.2 non-coated RV 10.3 non-coated
RV 10.20 coated RV 10.30 coated
1 1
1 1
1 1
1 -
1 Diagonal condenser 1 Vertical-intensive
condenser
1 Introduction sleeve 1 Vacuum connection
1 1
1 1
1 1
4 4
4 4
- -
- -
- -
- -
1 -
- -
- -
Drainage washer
Quantity
RV 10.4 non-coated RV 10.5 non-coated
RV 10.40 coated RV 10.50 coated
1 1
1 1
1 1
1 1
1 Dry ice condenser 1 Vertical condenser 1 Vertical-intensive
- 1 Vacuum connection 1 Vacuum connection
1 -
1 1
1 1
4 2
4 2
1 -
- 1
- 1
- 1
1 1
- 1
- -
RV 10.6 non-coated
RV 10.60 coated
1 1
1 1
1 1
1 1
condenser
1 1
1 1
1 1
4 4
4 4
1 1
- -
- -
- -
1 1
- -
1 1
