ASSEMBLY SAFETY CHECKS

Part Condition
Slides
Inserted through the bevel neck and
connected to the cutting head.
Locating lugs successfully deployed.
Slide Carriage
Inserted into threaded hole in the Bevel Neck.
Locking Screw
Anti-vibration spring fitted beneath the Locking
Screw Hand Knob.
Positive stop
Installed onto locking mechanism.
locking lever
Mitre locking
Installed onto locking screw.
handle
Power cable
Routed correctly and fastened to back slide bracket.
50-60mm max deflection at the midpoint.
ALL THE YES BOXES MUST BE TICKED BEFORE THE MACHINE CAN BE USED.
ANY 'NO' = DO NOT USE. STOP, CHECK AND REASSEMBLE BEFORE PROCEEDING.
IMPORTANT: Only use the dust bag* when cutting wood.
Remove when cutting metallic materials.
*Can be purchased as an accessory.
