Tools Needed
Watch and Learn
Carefully remove all of the parts from the packaging and check that all parts are present
and correct.
ITEMS SUPPLIED
BLADE PACKAGING SUMMARY
INSTRUCTIONS
INSTRUCTION MANUAL (Assembly)
INSTRUCTION MANUAL (Operations)
ROTARY BASE AND NECK
CUTTING HEAD (with Moulded Plug)
CARRIAGE SLIDES (colour coded)
MITRE LOCKING HANDLE
POSITIVE STOP LOCKING LEVER
HOLD DOWN CLAMP
HEX KEYS(s)
(assembly and blade change)
www.evolutionpowertools.com
MARKET SPECIFIC ACCESSORIES
(Not supplied as standard in all markets.
Available as a customer cost optional
accessory. See Operation manual for full
application details)
BLANKING PLUG
(To blank extraction port when cutting Steel)
ADAPTOR TUBE
(For connecting extraction port to
commercial extraction equipment)
LENS CAP
(For laser protection)
• Identify the parts and note that some of the
main parts are colour coded to aid assembly.
