CONTROL UNIT
4. ADVANCED PROGRAMMING
4.1

PROGRAMMING PARAMETERS

IMPORTANT! Before you start programming parameters, make sure that the gate is CLOSED and STOPPED and
that the SELF-TEACH procedure has been completed.
To program the parameters, follow the instructions given in Fig.5 and Tab. 2 below.
!
Warning
All input signals will be ignored during programming.
Press and hold down the RED button until the letter P appears on the display. Release the button
a programmable parameter will appear on the display.
To scroll through the parameters, press the BLUE button.
To leave the programming mode and return to normal operation, press the YELLOW button.
To display the current parameter value (shown by a bright dot), press the RED button;
available, press the BLUE button.
To modify a value, press the RED (Confi rm) buttonfor 3 seconds when the value required is displayed
is displayed (confi rmed by 3 fl ashes) and the system leaves the programming mode and returns to normal operation.
If you decide not to modify a value, press the YELLOW button. The display will return to showing the initial letter of the parameter.
Note: The OPERATING MODES and the signal responses are described in sect. 5.1.
Fig.5
Red to enter
programming
mode
Tab. 2
: wing closing delay
0 = 4 seconds (*)
Note: the delay
1 = 8 seconds
time on opening
2 = 12 seconds
is fi xed at 3
3 = 16 seconds seconds.
: short inversion (ms.)
0 0
1 30
2 (*) 50
3 80
4 100
5 120
6 150
7 200
8 300
9 400
: approach time (sec.)
0 = 2
1 = 4 (*)
2 = 5
3 = 6
4 = 7
5 = 8
6 = 10
7 = 12
8 = 14
9 = 16
IMPORTANT NOTE:
Blue
To select
Release
Blue
to select parameter
to be modifi ed
CAUTION: any increase in this
: thrust force
parameter causes a reduction in
0 = Low
obstacle recognition sensitivity.
1 = Medium
If a value of 3, 4, or 5 is set,
use special detection devices
2 = High (*)
on the basis of correct risk
3 = Very high
assessment.
4 = Medium wind
5 = Strongly wind
: prefl ashing reverse stroke
0 (*) no
1 no
2 yes
3 yes
4 no
5 no
6 yes
7 yes
: Pause time
photocell
0 (*) NO
1 NO
2 YES
3 YES
4 NO
5 YES
Yellow
Red
To confi rm To exit
RSK24-2000/2500
Red
to confi rm
parameter
trhust at end
of movement
no no
yes no
no no
yes no
no yes
yes yes
no yes
yes yes
Input function
J1 pin 6-9
PEDESTRIAN START
OPENING SAFETY SAFETY EDGE
PEDESTRIAN START
OPENING SAFETY SAFETY EDGE
OPENING SAFETY PHOTOCELL
OPENING SAFETY PHOTOCELL
- 20 -
the initial letter of
to scroll through the values
the new value
Blue
Red
to select to confi rm
new value new value
: Operating mode
0 = AUTOMATIC (*)
1 = 4 STEPS
2 = SUPER AUTOMATIC
3 = SEMIAUTOMATIC with STOP
4 = STEP-BY-STEP
: wing travel speed
0 = 50%
1 = 70% (* RAIDER2000)
2 = 85% (* RAIDER2500)
3 = 100%
CAUTION When the S (speed) parameter
is changed, you must perform the self-
teach procedure again. To do this, press
and hold down the YELLOW and BLUE
buttons together for a few seconds (see
section 3.1).
: pause time (sec.)
0 = 0
1 = 5 (*)
2 = 10
3 = 15
4 = 20
5 = 25
6 = 30
7 = 35
8 = 40
9 = 45
( ) = default values
*
