MAINTENANCE SPECIFICATIONS
BRACKET DIMENSIONS
Symbol
World wide
Unit
B1
mm (in)
B2
mm (in)
B3
mm (in)
B4
mm (in)
B5
mm (in)
B6
mm (in)
B7
mm (in)
B8
mm (in)
B9
mm (in)
B10
mm (in)
B11
mm (in)
B12
mm (in)
C1
mm (in)
C2
mm (in)
C3
mm (in)
D1
mm (in)
D2
mm (in)
D3
mm (in)
D4
mm (in)
T1
mm (in)
MAINTENANCE SPECIFICATIONS
Model
Ray 8
70.5 (2.8)
198 (7.8)
95.3 (3.8)
112 (4.4)
105.3 (4.1)
207 (8.1)
—
—
18 (0.7)
—
—
—
28 (1.1)
65 (2.6)
—
8.3 (0.3)
8.3 (0.3)
—
—
—
2-21
