Electric wire rope winch >BETA II<
English
2.3. Main dimensions
For detailed specification please ask for our dimensional sheet.
Size 1 - 5
Size M 0
Type
Size M 0
Size 1
Size 1.5
Size 2
Size 3
Size 3.5
Size 4
Size 5
3.
Mounting Instructions
3.1. Mounting:
Attention
After having removed the transport blocks the winch may tilt to the
motor side. Therefore the winch has to be secured against tilting
before mounting.
Pay attention to crane suspension points! (not at size M0)
The mounting structure must be designed to sustain the max.
forces imposed by the winch (impact coefficient acc. to DIN15018
has to be considered)
Pay careful attention that the mounting surface is flat and true.
Only fix the winch by means of good quality screws.
Tighten the screws evenly.
Secure the screws.
Pay attention to unhindered rope coiling!
3.2. Mechanical fixing:
Size
screws
material grade
number of screws
tightening torque [Nm]
design changes under reserve
A
B
[mm]
[mm]
185
170
215
300
215
300
270
400
320
510
320
510
380
660
430
800
M0
1
1.5
M10
M 12
M 12
4
4
40
70
70
04.01.401
ØC
D
[mm]
[mm]
12
5
13,5
6
13,5
6
18
8
22
10
22
10
26
12
34
15
2
3
M 16
M 20
min. 8.8
4
4
4
170
340
E
G
[mm]
[mm]
185
200
325
340
325
340
444
465
547
570
547
570
687
720
844
882
crane suspention points
transport blocks
3.5
4
5
M 20
M 24
M 30
4
4
4
340
590
1200
page 25
