• Replacing battery pack
Position the battery pack over the down tube (with some space between the seat tube and the lower
end of the battery pack, step 1 below). Now, slide the battery pack down onto the rail (2). Use the
lever to lower the battery pack carefully during the last phase of sliding, so that the connectors
engage (3). Be sure that the connector at the bottom of the battery pack and the connector on the
docking engage properly. When the battery pack is fully in place, push the lock in until it clicks (4).
Do not ride the bike with the lock open.
1
3
EN-23
u
se
2 3
5
Contacts at the bottom side of the down tube.
