Trek Ride+ Manuel Du Propriétaire page 20

I
nstruCtIons for
• Switching lights On/Off
Press the button for 2 seconds to switch On/Off the controller
display light, and, if present, the front and rear lights. This switches
on the front light, the rear light, and the backlight in the display.
The lights will stay On even when you stop. Even when the battery
gauge shows 'empty', there is enough energy to run the lights for
about two hours. If the battery pack is fully drained, the lights will be powered by the system as it
switches to generative mode automatically. To switch the lights Off, hold the button for 2 seconds.
• Mountain mode
The "Mountain Mode" allows for longer uphill riding before the motor shows power reduction due to
so-called "temperature-derating". As "Mountain Mode" limits the maximum motor torque the motor
will stay cooler for a longer period of time. Select this option by going to assistance level 4 and then
press-and-hold the '+' button for 2 seconds. To return to assistance level 4, press the '-' button once.
• Removing and installing the BionX G2 controller
To remove the BionX G2 controller from the bike, press the catch at
the back of the holder and slide the controller off towards the rear.
To install the BionX G2 controller onto the handlebar, align the
controller with its clamp and slide the controller forward until it clicks.
NOTICE. To prevent loss of riding information, please make sure that
the system is switched Off before the controller is removed from the bike.
• Unintended removal of controller out of its dock
If the controller is moved off its clamp while the system is active ('On'), the system will no longer
assist, even when the controller is replaced into its clamp. Please select the correct level of
assistance again to reactivate the system.
• Using the BionX remote
Most bikes with the BionX G2 controller positioned on the middle clamp are equipped (or can be
equipped) with the BionX remote. This device is mounted either the right or left side of the
handlebar and can be used to regulate the following functions without moving your hands off the
handlebar:
1. '+' button
2. '-' button
3. Throttle button For Pedelecs: walk assist up to 4 km/h (pedaling not needed)
• Installation of the BionX remote for non-equipped bikes
To connect the BionX remote to the system, the remote connector can be plugged into the receiver
connector of the controller docking. After that, the brake generator connector can be plugged into
the remote connector. The red throttle button on the BionX remote is a convenient help to move
the bike without pedaling (up to 4 km/h) walking next to the E-bike.
WARNING. Beware of unintended use of the throttle button when the system is switched On.
EN-17
u
se
Increase assist level (or decrease regeneration level)
Decrease assist level (or increase regeneration level)
For fast E-bikes: assist up to +/- 20 km/h (pedaling not needed)
1
2
3
