BML-M0 -I -A
Magnetic Tape – Incremental Magnetically Coded Position Measuring System
7
Type code breakdown (continued)
7.2

Type code breakdown for tape with one reference point

Magnetic tape
Construction
02 = linear, incremental, 1.55 mm thick, with adhesive layer
03 = linear, incremental, 1.35 mm thick, without adhesive layer
Type
I = Incremental
Pole width
3 = 1 mm
4 = 5 mm
Accuracy class
4 = 8 µm (only with 1 mm pole width)
5 = 18 µm
6 = 50 µm (only with 5 mm pole width)
Cover strip
0 = without cover strip
3 = with cover strip
Length in cm
0200 = ordering length 200 cm (0007...4800)
Reference point position in cm
R0010/0000 = Reference point at 10 cm (any position possible).
The position is calculated from the beginning of the tape.
18 english
_
-...
BML - M02 - I 4 6 - A0 - M0200 - R0010/0000
