6. SOFTWARE CONFIGURATION
6.2.2 DEVICES

6.2.2.6 UCOUNT

• Description: You can make a brief description of the UCount (i.e.:
Quick Service UCount)
• Address: The system sets a local address automatically. You can
rename it just in case you need it.
• Associated Tank: You have to associate the tank that is physically
connected to the device.
• Display Quantity: Activates or deactivates the showing of the
transaction on the display integrated on the device. If this option is
not chosen, moving arrows are showed on the display during the
transaction.
• Pulsemeter Value: This parameter corresponds to the nominal
value of the Pulse meter that is connected to the UCount.
• SV Aperture Delay: Regulates the time the solenoid valve takes to
open after the transaction confirmation.
• Suspension Time: Regulates the pause time without receiving
pulses from the pulse generator. If the transaction is interrupted for
a time longer than this value, the transaction is counted as finished
and the solenoid valve closes automatically.
• Top Up Time: Regulates the waiting time after the initial transaction
is completed, making it possible to do an additional topping in the
same transaction although the preset quantity is achieved. After this
stated time it is not possible to dispense an additional quantity to
the transaction and it is considered as completed.

6.2.2.7 UVIEW

• Description: You can make a brief description of the UVision (i.e.:
Quick Service UView).
Once you have set all the parameters, please press

6.2.2.9 UVISION+

• Description: You can make a brief description of the UVision (i.e.:
Quick Service UView).
• Address: Address of the device to which the UVision is connected
to (UValve or UMeter+).
• Mode: Normal, Preset and Workorder Validation. (NOTE: The Preset
mode can only be made when the PRESET mode is chosen in the
GENERAL Screen).
Once you have set all the parameters, please press

6.2.2.11 MOBILE UNIT

First of all, I have to say that this is considered as a tank although it is a
set of UValve / UDat. In this menu you have to define the parameters of
the tank that contains each product already defined in the previous tab.
• Description: You can make a brief description of the UVision (i.e.:
Quick Service UVision).
• Local Address: The system sets a local address automatically. You
can rename it just in case you need it.
• Select Product: You have to choose the product that is contained
in the tank. The products will be the ones already defined in the
previous tab.
32
838 861 R. 11/21
SAMOA Industrial, S.A. · Pol. Ind. Porceyo, I-14 · Camino del Fontán, 831 · 33392 - Gijón - Spain · Tel.: +34 985 381 488 · www.samoaindustrial.com
For example, we have ordered 4 litres and after that these 4 litres
have been dispensed, this is the time available for making an
additional topping to the original transaction (for example another
0.2 litres, because even if we initially thought that the crank case had
4 litres, when the 4 litres are dispensed and the dip stick is checked
we see that we need to fill in a little more). During this time, the
display integrated in the device will show "top", giving the
possibility to extend the transaction.
• Remote Display 1: Selection of a remote display (UView) to show
the volume that is being dispensed.
• Remote Display 2: Selection of a second remote display (UView)
to show the volume that is being dispensed.
• K Factor: You can change the calibration factor if it already known.
In any case, it is automatically changed when the calibration
procedure is made in the UDat.
• Max Quantity: Regulates the maximum quantity that is possible to
dispense in one transaction with previous preset value, including the
first transaction and the topping (additional filling up quantities).
• Product Label for UVision: If a UVision is linked to this UValve,
you can set a small name that will appear on the upper right part of
the UVision screen.
Once you have set all the parameters, please press
6.2.2.8 UVISION
• Description: You can make a brief description of the UVision (i.e.:
Quick Service UVision).
and then . Once you have set all the parameters, please press

6.2.2.10 AIR SV

• Description: You can make a brief description of the UVision (i.e.:
Quick Service UVision).
• Selected UTank: You have to set the UTank number which the
Solenoid Valve is connected to.
Once you have set all the parameters, please press
and then .
• Choose a colour: You can associate a colour to the product
contained in the tank.
• Select Tank: You can choose the shape of the tank. If you click, you
will see a drop-down menu. In that menu you will find several
predefined tanks.
• In any case, if the installed tank is not in the list, you can define the
tanks with the
appear.
and then
and then
and then
button. If you press it a popup window will
.
.
.
