7. MANAGER
7.6 DEVICES
7.6.1 DISPENSE POINT
• Pulse meter value: This parameter corresponds to the nominal
value of the pulse meter. For example, the UValve incorporate a
pulse generator of 328 Pulses per litre. The allowed range is 10
to 1000 pulses per litre.
• SV aperture delay: Regulates the time the solenoid valve takes
to open after the transaction confirmation. The allowed range is
0 to 600 seconds.
• Suspension time: It regulates the pause time without receiving
pulses from the pulse generator. If the transaction is interrupted
for a time longer than this value, the transaction is counted as
finished and the solenoid valve closes automatically. The allowed
range is 0 to 900 seconds.
• Top Up time: It regulates the waiting time after the initial
transaction is completed, making it possible to do an additional
topping in the same transaction although the preset quantity is
achieved. After this stated time it is not possible to dispense an
additional quantity to the transaction and it is considered as
completed. For example, we have ordered 4 litres and after that
these 4 litres have been dispensed, this is the time available for
making an additional topping to the original transaction (for
example another 0.2 litres, because even if we initially thought
that the crank case had 4 litres, when the 4 litres are dispensed
and the dip stick is checked we see that we need to fill in a little
more). During this time, the display integrated in the UValve or
UCount will show "top", giving the possibility to extend the
transaction. The allowed range is 0 to 1800 seconds.
• Remote Display 1 / Remote Display 2: If any UViews are
installed, it is possible to show the delivered quantity in up to
two UViews. You can set the UView number in this menu.
• Max Quantity: In this option it is possible to set the maximum
quantity that can be delivered through this device. The allowed
range is 0 to 999 litres.
• K Factor: This is the calibration factor that is automatically set
when the calibration procedure is followed in the device. In any
case, it is possible to change it manually if the value is already
known. The allowed range is 500 to 1500.
• Display Quantity: Activates or deactivates the showing of the
transaction on the display integrated on the UValve or UCount.
If this option is not chosen, falling angles are showed on the
display during the transaction.
• Ninth column: It shows if the device is in bypass mode via software
or not. If it is not, the padlock is closed. If so, it is open. You can set
the device to bypass mode (open solenoid valve) by clicking on the
padlock.
• Tenth column: If you press
case it gets frozen.
In the upper right part of the window there are three icons:
The first one refreshes the readings; the second one allows to make
a search in the table and the third one allows to export data to a MS
Excel spreadsheet.
SAMOA Industrial, S.A. · Pol. Ind. Porceyo, I-14 · Camino del Fontán, 831 · 33392 - Gijón - Spain · Tel.: +34 985 381 488 · www.samoaindustrial.com
the device gets rebooted just in
EN
43
