AccESSING yOUR hOOk ShARPENER:
Your fishhook sharpener is stored in a watertight compartment inside the main sharpening unit.
The access cover for the hook sharpener is located on the lower left side of the sharpening
station. To access the hook sharpener, pull the edge of the cover out as shown in Figure 17a,
then remove the cover by sliding in the direction of the arrow to remove (Figure 17b). The hook
sharpener can then be removed from its compartment by gripping the tip with your fingers and
slowly sliding it out of its compartment (Figure 17c). It may be easier to tilt the sharpening station
sideways once the access cover is removed to make the hook sharpener more easily accessible.
Two AA batteries need to be installed in the hook sharpener before use. Holding the upper
(white) part of the hook sharpener firmly in one hand, twist the lower part (blue) half-way coun-
ter-clockwise and pull to separate the battery compartment. Insert two fresh AA batteries** into
the compartment with the polarity as shown in Figure 18. Reverse the process to re-assemble
the hook sharpener, using the markings on the unit as a guide for alignment.
**Please note: never mix old and new batteries. New alkaline batteries are recommended for best performance.
**Remove batteries from Hook Sharpener during extended periods of storage or non-use.
**AA batteries not included.
Figure 17a. Lift cover edge off.
Figure 18. Correct battery insertion.
All manuals and user guides at all-guides.com
hOOk ShARPENER
BEFORE FIRST USE
Figure 17b. Slide to the left and
remove cover.
17 17
Figure 17c. Remove hook sharpener
from main unit.
