Note: For assistance and reporting of issues associated with the RCM device, contact your Health
Care Provider or authorised ResMed representative.
RCM at a glance
Refer to illustration B.
1. Stand
2. Wall mounting socket
3. Indicator panel
4. Micro-USB port
5. Power inlet
Indicators
Refer to illustration C.
RCM provides indication of the current operating state. When the Power and Vent. Input indicators
illuminate and you have network reception, RCM is ready to use.
Indicator
1 Power – Green
Indicates whether RCM is powered on.
2 Vent. Input – Blue
Indicates whether RCM is connected to the powered-on
ventilation device.
3 Signal – Blue
Indicates connectivity to the cellular network and the signal
strength.
4 Error – Yellow
Indicates whether RCM has an error.
Note: The Vent. Input and Signal indicators will dim in 5 minutes and will return to full brightness when RCM is
connected to the ventilation device or powered on again.
2
6. Wall mount
7. Power Supply Unit (PSU)
8. Plug blade attachments
9. USB cable (not shown)
Status
On: The power is on.
Off: The power is off.
On: Connected to the ventilation device.
Off: Disconnected from the ventilation device.
Blinking: Establishing connection to the ventilation device.
On: Connected to the cellular network. The signal strength
is indicated by the number of blue dots (more dots mean a
stronger signal).
Off: No cellular network detected.
On: An error has occurred.
Off: No error
