EtherNet link object, class F6h

Object descrip- The EtherNet link object groups diagnosis information for EtherNet interfaces.
tion
Supported func-
Class functions:
tions
Instance functions:

Class attributes

# Access Name
1 Get
2 Get
3 Get
Instance attrib-
# Access Name
utes
1 Get
2 Get
3 Get
6 Get/Set Interface Con-
108
All attributes
Individual attributes
All attributes
Individual attributes
Type
Revision UINT
Max Instance UINT
No. of instanc- UINT
es
Type
Interface UDINT
Speed
Interface DWORD
Flags
Physical Ad- Array of 6
dress USINTS
Struct of:
trol
WORD
UINT
Value Description
0001h Revision 1
0001h 1 is the highest in-
stance number
0001h 1 instance is imple-
mented
Value Comments
10 or 100 Actual ethernet inter-
face speed
- -
(MAC ID) Physical network ad-
dress
- Auto-negotiation, du-
plex, and speed.
