PERSONAL INJURY POTENTIAL
Remove all ice machine panels before lifting and
installing.
Location Requirements
The location selected for the ice machine must meet the
following criteria. If any of these criteria are not met,
select another location.
•
The location must be free of airborne and other
contaminants.
•
The location must not be near heat-generating
equipment or in direct sunlight.
•
The location must be capable of supporting the
weight of the ice machine and a full bin of ice.
•
The location must allow enough clearance for water,
drain and electrical connections in the rear of the ice
machine.
•
The location must not obstruct airflow through or
around the ice machine.
•
The location must not allow exhaust fan heat and/or
grease to enter the condenser.
•
The location must allow electrical, water, drain and
refrigeration tubing to enter the ice machine from the
back.
•
Local water conditions may require treatment of the
water to inhibit scale formation, filter sediment, and
remove chlorine odor and taste.
These ice machines are intended for use in household
and similar applications such as:
•
Staff kitchen areas in shops, offices and other work
enviroments.
•
Clients in hotels, motels, farmhouses, bed and
breakfast and other residential type enviroments.
•
Catering and similar non-retail applications.
Part Number 000006505 12/10
Warning
Section 2
Installation
MINIMUM/MAXIMUM TEMPERATURES
Model
All Ice Machine Head
Sections
CVD0685 - CVD1185
CVD2085 - CVD3085
CVD0885 - CVD1085
CVD1285 - CVD1485
CVD1885
CVD1486
ICE MACHINE CLEARANCE REQUIREMENTS
Model
S0600C - S0800C
S1000C - S1200C
S1470C - S1870C
S2170C
IB0600C - IB0800C
IB1000C
S3000C
* Routing utilities out top - Routing utilities out back
** 24" (61 cm) is recommended on all sides
CONDENSING UNIT CLEARANCE REQUIREMENTS
Model
CVD0685 - CVD0885
CVD1085 - CVD1185
CVD1885 - CVD2085
CVD1285 - CVD1485
CVD1885
CVD1486
CVD3085
* 24" (61 cm) is recommended on top/sides
Minimum Air
Maximum Air
Temperature
Temperature
35°F
110°F
2°C
43°C
-20°F
120°F
-29°C
49°C
-20°F
130°F
-29°C
54°C
35°F
110°F
2°C
43°C
Top
Back
5"
*3" - 5"
13 cm
*8 - 13 cm
2"
5"
5 cm
13 cm
8"
24"
20 cm
61 cm
Top/Sides
Back
*6"
48"
*15 cm
122 cm
*6"
48"
*15 cm
122 cm
*5"
12"
*13 cm
30 cm
*6"
24"
*15 cm
122 cm
Sides
5"
13 cm
8"
20 cm
**8"
**20 cm
Front
48"
122 cm
24"
61 cm
12"
30 cm
24"
122 cm
5
