Refrigeration System Installation

Remote Single
QuietQube®
Ice Machine
Condenser
S0600C
IB600C
S0800C
IB800C
S1000C
IB1000C
S1200C
S1470C
S1870C
S2170C
S3000C
Suction
*Line Set
Line
5/8 inch
RC 21/31/51
(16 mm)
3/4 inch
RC 20/30/50
(19 mm)
3/4 inch
RC 23/33/53
(19 mm)
Two Lines -
3/4 inch
RC 24/34/54
(19 mm)
Important
Manitowoc remote systems are only approved and
warranted as a complete new package. Warranty
on the refrigeration system will be void if a new ice
machine head section is connected to pre-existing
(used) tubing or condensing units or vice versa.
Part Number 000006505 12/10
Circuit Line Set*
CVD685
RC-21
RC-31
CVD885
RC-51
CVD1085
CVD1185
CVD1285 RC-20
RC-30
CVD1485
RC-50
CVD1486
CVD1885
RC-23
CVD2085 RC-33
RC-53
RC-24
CVD3085 RC-34
RC-54
Minimum
Liquid
Insulation
Line
Thickness
1/2" (13mm)
3/8 inch Suction Line
(10 mm) 1/4" (7mm) Liquid
Line
1/2"(13mm)
1/2 inch Suction Line
(13 mm) 1/4" (7mm) Liquid
Line
1/2"(13mm)
5/8 inch Suction Line
(16 mm) 1/4" (7mm) Liquid
Line
3/4"(19mm)
One Line -
Suction Line
5/8 inch
1/4" (7mm) Liquid
(16 mm)
Line
! Caution
The refrigeration system warranty will not apply if
the Manitowoc Ice Machine and Manitowoc CVD
Condensing Unit are not installed according to
specifications. This warranty also will not apply if
the refrigeration system is modified with a
condenser, heat reclaim device, or other parts or
assemblies not manufactured by Manitowoc.
Ice Machine Refrigerant Amounts
ICE MACHINE HEAD SECTION
Each ice machine head section ships from the factory
with a R-404A refrigerant charge appropriate for the
entire system operation. The serial tag on the ice
machine indicates the refrigerant charge. The refrigerant
charge is sufficient to operate the ice machine at all
ambients with lineset lengths up to 100 feet (30 m).
!
Potential Personal Injury Situation
The ice machine head section contains the
refrigerant charge. Installation and brazing of the
line sets must be performed by a properly trained
and EPA certified refrigeration technician aware of
the dangers of dealing with refrigerant charged
equipment.
!
Installation of a QuietQube® Condensing Unit may
require the use of special equipment for placement.
Trained and qualified personnel are required for
proper rigging and lifting. Holes are provided on the
corners of the condensing unit to allow the use of
lifting shackles.
Installation
