Follow the following steps for set-up:
Preprogramming of the Somfy io-homecontrol
1)
Checking the rotation direction (§2. 3. 3)
2)
Setting the end limits (§2. 3. 4)
3)
Setting advanced functions (§2. 3. 5)
4)
Programming of the Somfy io-homecontrol
5)
2. 3. 2. Preprogramming of the Somfy io-homecontrol
Simultaneously press the "Up" and "Down" buttons:
-
This control point is now preprogrammed in the drive.
Preprogramming is lost if power to the drive is
switched off before the control point is registered.

2. 3. 3. Checking the rotation direction

Press the "Up" button:
1)
If the driven product raises, the rotation direction is
correct.
If the driven product lowers, the rotation direction
is incorrect. Press the "my" button until the driven
Press the "Up" button to check the rotation direction.
2)

2. 3. 4. Setting the end limits

The procedure used to set the end limits depends on
the equipment of the driven product (see table below).
Pressing and holding the "Up" or "Down" buttons causes the driven product to raise or
lower continuously.
Available devices
a
Top Catching system at lower
stop end limit
None Manual
-
-
- -
*Automatic
a heavy load bar and a top stop.
54
b c
Heavy
load
bar
*Auto.
- -
- -
- -
- -
- -
Non contractual images
local control point (§2. 3. 2)
®
local control point (§2. 3. 6)
®
local control point
®
1)
2)
a
Steps to be
performed
See E1
See E2
See E3**
b
See E4
See E5
Copyright © 2015 Somfy SAS. All rights reserved.
0.5
S
The rotation
direction is
correct
