AVENTICS | RTC-CG/RTC-HD/CKP | R412025608–BAL–001–AA | English
9 Control example
Mounting orientation horizontal
P1
2
1
Mounting orientation vertical
2
1
2
1 3
10 Disposal
O Dispose of the device in accordance with the currently
applicable regulations in your country.
P3
P4
P2
2
1
4 2
5 1 3
P1
P4
P2
2
1
2
1 3
11 Technical data
General data
Dimensions (W x H x D)
Weight
Min./max. operating pressure
Ambient and medium temperature
Medium
Particle size
Oil content of compressed air
4 2
Mounting orientation
5 1 3
Shock absorber mounting
orientation
Volume per stroke
P3
4 2
5 1 3
14
153.6 mm x
46.8 mm x
54.5 mm
0.727 kg
4 bar/8 bar
-10 °C/60 °C
Compressed air
≤ 5 μm
3
≤ 1 mg/m
Any
Any
3
4.6 cm
