NTP SERvER OUTPUT CONfIGURaTION
If your product is provided with a NTP server card, the following panel will be displayed:
Offset from UTC cannot be configured, as the card deliver NTP time code in UTC. To
configure finely the NTP server card, you need to open its own WEB page, described
in the following chapter.

4.3. WEB INTERfaCE Of NTP SERvER OUTPUT CaRD

4.3.1. Network and SNMP setup
To configure network and SNMP parameters, the NTP server output card provides the
same WEB panels than the LEDI Network IN (see below). Please refer to parts 2.2 and
2.3 for more details. The NTP server MIB is detailed in page 40.
Status bar
The status bar is positioned on bottom of the WEB page. It gives information about the NTP
server software. It contains the following information:
Current UTC time
delivered through NTp
MDE-LEDI-NETWORK-IN-4065V1.0
phase difference
between software clock
and time code
delivered by hardware
4. WEB INTERfaCE
Current state of Synchronization
NTp software state
