This appendix contains a description of the different connectors of the LEDI Network
IN. All the plugs are localized on the backside of the product.

1. CONNECTION fOR aLL PRODUCTS

1.1. 230V and 115V AC product (type '0')
The backside of the product has a standard power supply plug, the Ethernet RJ45 plug
and a RESET button as shown below:

1.2. 18/72V DC product (type '9')

The Ethernet connector and the RESET button are the same.
Only the power supply plug is different.
MDE-LEDI-NETWORK-IN-4065V1.0
aPPENDIx
a – CONNECTIONS
+V DC
0V
93
