3. DUaL afNOR/IRIG-B NfS87500 DCLS RS422 aND TTL OUTPUT
('T' TYPE)
This card has its outputs on a 4 points plug and a BNC connector. The RS422 AFNOR code
is available on the 4 points output :
The BNC connector provides TTL signal :
MDE-LEDI-NETWORK-IN-4065V1.0
Tx/Rx +
1 2 3
aPPENDIx a – CONNECTIONS
Tx/Rx -
4
Tx
GND
