5.3. Example of how to use the static relay output (pins 1-2)

VCC
pulse
WARNING : You must ensure that
MDE-LEDI-NETWORK-IN-4065V1.0
loudspeaker
R
1
2
aPPENDIx a – CONNECTIONS
+
External
WaRNING :
V max = 60 Volts
DC or AC
-
Power
Supply
V
i = < 130 mA
R
99
