3.1. Equipment Versions
Commercial derope™ STD
designation Fig.1
Standard derope™
Description
descender.
Controlled-speed
Functional
descender for vertical
description
evacuation.
- Descender.
Composition of - Rope.
delivery - 3 connectors.
- Manual + Compliance certificate.
3.2. Equipment Diagrams
4 7
8
3
1
2
5
6
Fig. 1 Fig. 2
1: casings
2: clam cleat
3: rope guide
4: upper connector
5: rope
6: rope end connector
7: handwheel
8: folding handle
9: mounting bracket for ladder with locking system
10: locking slide
11: locking pin
12: fastening pin
13: indexing pin
14: belay lanyard connector
15: adjustment device LCM 05
16: connector for adjustment device LCM 05
17: belay lanyard
18: small support bracket
19: locking pin
20: fastening pin
21: safety pin
22: bracket rope guide
23: rope blocking device
24: locking screw

3. Presentation of Equipment

derope™ UP A derope™ UP B
Fig.2
derope™ descender
derope™ descender with equipped with recovery
Recovery system. system equipped with
large bracket.
derope™ UP A
derope™ STD descender
descender equipped
equipped with rescue
with a mounting bracket
function for lifting up
for ladder with locking
using a handwheel.
system.
- Descender.
- Rope.
- 2 connectors.
- Belay lanyard equipped with two connectors and
length adjustment device LCM 05.
- Mounting or support bracket.
- Manual + Compliance certificate.
9
14
12
13
10
11 17
15
Fig. 3
derope™ UP K
Fig.3 Fig.4
derope™ descender
equipped with recovery
system equipped with
small bracket.
derope™ UP A des-
cender equipped with
a support bracket for
ladder.
19
18
16
Fig. 4
GB
derope™ UP R
Fig.5
derope™ descender with
recovery system supplied
with bracket for rigging
tripod.
derope™ UP A des-
cender equipped with
a mounting bracket for
Tractel tracpode rigging
®
tripod.
- Descender.
- Rope.
- 2 connectors.
- Mounting bracket
equipped with fastening
pin for tripod.
- Manual + Compliance
certificate.
23
22
21
24
20
Fig. 5
