Commissioning
Calibrate filling level
The flask level sensor S4 can be calibrated via the menu item
level
Main menu
(
101.
Maximum pressure
Max. pressure
Via the
(corresponding to atmospheric pressure + compressor pressure) can be set within a range of
1,100 –1,400 mbar.
The higher the target pressure, the better the performance of the system.
An adjustment may also be necessary if larger distances or heights (e.g.
tanks) have to be overcome.
Please note that exceeding a target pressure of 1,400 mbar during
operation activates the overpressure shutdown of the evaporator and the
system is ventilated.
Sensitivity cut-out sensor S3
Sensitivity cut-out sensor S3
Via the
gency stop sensor can be adjusted in a range of 0 –100 % in steps of [1 %].
The
be changed by authorized technical personnel during installation or after
consultation with the Heidolph application engineering department.
The standard setting covers most applications, an adjustment is only
necessary for extremely low- or high-polarity media.
Factory settings
The device can be reset to the factory settings via the menu item
Main menu
Settings
(
→
141.
Selecting the user language
Languages
In the
menu (
changed at any time. Available languages are English, German, Mandarin, French, Spanish,
Portuguese, Italian, Russian and Polish.
Languages
➜
Touch the
➜
The list of all available menu languages opens.
➜
Touch the entry for the desired language.
➜
The background color of the selected entry changes to orange.
ok
➜
Press
to confirm the selection and to return to the Start window of the active mode.
discard
➜
Touch the
active mode without making any changes.
Settings
→
), see section „Calibrate the flask level sensor" on page
. menu item, the maximum permissible absolute target pressure
Sensitivity cut-out sensor S3
), see section „Resetting the device to factory settings" on page
Main menu
Languages
→
function button.
button to discard the entry and to return to the start window of the
Calibrate filling
menu item, the sensitivity of the emer-
parameter may only
Factory settings
), the user language can be
110
