33
SPINDLE ASSEMBLY
* Not illustrated
ITEM
PART NO
2
001791171
3
148070
4
MBG5500
5
MBG5448A
6
002993160
7
143030
8
143032
9
001791189
10
143031
11
148071-01
12
450944
13
142108.7
14
112243-03
15
450393
16
001009770
17
64209-03
18
450020176
19
450479
All manuals and user guides at all-guides.com
DESCRIPTION
Snap Ring, 1.187"
Bearing-Ball 1-1/4 10
Spindle Housing
Extension
Lubricator-M6 X 90 Deg
Spindle
Spacer-Bearing
Snap Ring, 1.250"
Spacer-Seal
V-Ring V-60a
Scrw-set M4 X 10, Cup Pnt
Cap-Spindle
Blade
Wshr-M16 X 30 X 3.3
Bolt-hex 5/8-18 X 7-3/4
Spring Washer .67 Id
Nut-hex 5/8-18
Scrw-hex M10 X 25 Verbus Ripp
960 FRONTLINE
PARTS MANUAL
LIST OF PARTS
QTY
REMARKS
1
2
1
1
1
1
1
1
1
2
2
1
1
(Use 112243-02 On 9'-8" Wing
Decks, Qty 4)
1
1
1
1
4
Parts-105
