WING DECK
* Not illustrated
ITEM
PART NO
1
2218152-01
2
450214
3
450391
4
2212097.6
*
2212094.6
*
2212099.6
*
2212098.6
6
MBG5574.6
*
MBG5575.6
*
MBG5656.6
*
MBG5655.6
7
451970
8
002039152
9
146169
10
469009601
11
MBG5426
12
450073
13
W176061.7
14
MBG5427
15
002190200
16
MBF2195.6
17
450239
18
450424
19
MBF2196.6
20
450380
21
452626
24
MBF2194.6
25
64188-29
26
MBF1969
27
450171
28
001490226
29
450379
30
MBF1947.6
*
MBF1948.6
*
MBF1990.6
*
MBF1989.6
31
W176059.7
32
MBF1959
*
MBF1958
MBF1958
MBF1959
33
450412
34
MBF6038
All manuals and user guides at all-guides.com
DESCRIPTION
Motor 11cc
(Seal Kit 2218152-04)
(Use 2218152-02 On 10'-7"
Models)
Scrw-hex M10 X 25
Wshr-M10 X 21 X 2.2
Motor Plt-LH Deck
Motor Plt-RH Deck
Motor Plt-LH Deck
Motor Plt-RH Deck
Cover-deck LH Outer
Cover-deck RH Outer
Cover-belt Outer Lh
Cover-belt Outer Rh
Circlip-int 40 X 1.75 T
Brg-ball 17 X 40 X 12
Pulley Idler W/Bearg
(Includes Items 7 & 8)
Quick Pin
Washer
Bolt-hex M16 X 70
Swing Arm Assy-rear
Collar-1.266 X 2 X .500
Bush-flng 1.25"X1.50"X0.75"
Wldmt-Caster Arm
Scrw-hex M12 X 20
Lockwshr-M12 X 21 X 2.5
Wldmt-Yoke, Caster
Nut-hex M12 Nyloc
Bolt-crg M12 X 150
Wldmt- Caster Whl Brkt
Pin Clevis 1/2 X 6
Wldmt-Push Arm Pin
Scrw-hex M6 X 20
'R' Clip
Nut-hex M10 Nyloc
Wldmt-wing Deck LH
Wldmt-wing Deck RH
Wldmt-wing Deck LH
Wldmt-wing Deck RH
Wldmt-swing Arm Rear
Wldmt-adj Plate LH Deck
Wldmt-adj Plate RH Deck
On Left Wing Deck
On Right Wing Deck
Lockwshr-M10 X 15.9 X 2.5
Pulley-5.75 Od
960 FRONTLINE
PARTS MANUAL
LIST OF PARTS
QTY
REMARKS
2
16
16
1
On 9'-8" Models
1
On 9'-8" Models
1
On 10'-7" Models
1
On 10'-7" Models
1
On 9'-8" Models
1
On 9'-8" Models
1
On 10'-7" Models
1
On 10'-7" Models
2
2
2
2
2
4
2
10
4
2
16
16
2
2
1
2
2
2
2
2
4
1
On 9'-8" Models
1
On 9'-8" Models
1
On 10'-7" Models
1
On 10'-7" Models
1
1
On 9'-8" Models
1
On 9'-8" Models
1
On 10'-7" Models
1
On 10'-7" Models
6
4
Parts-101
