Textron RANSOMES JACOBSEN Frontline 960 Manuel De Maintenance page 145

5 FRAME - REAR
* Not illustrated
ITEM PART NO
1 2212072
2 2218000
3 MBG5364
3A 4128538
4 2212054A
5 2212051A
6 4125519
7 MBF1911
7A MBF1912
8 2212046
9 2212045
10 4125219
11 4125141
12 450120267
13 450378
14 450241
15 450392
16 452200029
17 450168
18 2218083
19 450191
21 452200176
22 450214
23 450391
24 450379
25 113006-01
26 MBA5289A
27 450192
28 450239
29 450455
30 MBG2637
31 4125539
32 450048
33 450542
34 450376
35 W178142
36 450380
37 2216033A
38 64166-17
39 MAA0335A
40 MBB6845A
41 009079280
42 64025-29
43 001191140
44 64002-02
45 450190
46 64006-02
All manuals and user guides at all-guides.com
DESCRIPTION
Screen-hood
Hood-plastic
Hinge-plate RH
Hinge-plate LH
Hinge-adj Rh
Hinge-adj Lh
Wldmt-Fan Shroud
Radiator Support
Wldmt-Louvre Panel
Gusset-LH
Gusset-RH
Wldmt-RH Frame Rail
Wldmt-LH Frame Rail
Nut-hex 3/8-16 Nyloc
Nut-hex M8 Nyloc
Screw-hex M12 X 30
Wshr-M12 X 24 X 2.7
Lockwshr-1/4 X .425 X .072
Scrw-hex M6 X 12
Lanyard
Scrw-hex M8 X 20
Lockwshr-1/2 X .873 X .125
Scrw-hex M10 X 25
Wshr-m10 X 21 X 2.2
Nut-hex M10 Nyloc
Bushing-.5x.32x.19 Lg
Wshr-8.5 X 25.5 X 3
Scrw-hex M8 X 25
Scrw-hex M12 X 20
Nut-hex M12 Verbus Ripp
Handle-hood
Wldmt-Rear Axle Support
Bolt-hex M12 X 40
Scrw-pan Hd M6 X 20
Nut-hex M5 Nyloc
Latch-rubber
Nut-hex M12 Nyloc
Wldmnt-Bumper
Blt-shldr 3/8-16x1.12
Wshr-17/32 X 25mm X 3/16
Toggle
Hook
Nut-hex #8-32 Keps
Scrw-RND HD No.8-32 X 1/2
Lckwshr-TH,Ext,#10
Scrw-hex M8 X 16
Lckwshr 5/16
960 FRONTLINE
PARTS MANUAL
LIST OF PARTS
QTY REMARKS
1
1
1
1
1
1
1
1
1
1
1
1
1
4
4
8
12
12
14
2
4
8
2
4
2
4
4
4
3
3
1
1
4
8
4
2
7
1
4
2
2
2
8
4
4
8
8
