17
COOLING & EXHAUST
* Not illustrated
ITEM
PART NO
42*
4127198
43
450453
44
4123047
45
48378
45
172212
45
172290
46
2213009
47
4122778
48
W048319-04
49
4122798
50
-
51
450411
52
450192
53
A691139
54
450727
55
MBG5543
56
4128648
57
MBG7022
All manuals and user guides at all-guides.com
DESCRIPTION
Insulation-Exhaust
Nut-hex M8 Verbus Ripp
Muffler
Strap- Rubber
Brkt-Upper Hanger
Brkt-Lower Hanger
Pipe-Muffler
Wldmt-Exhaust Pipe
Clamp-Muffler 2-1/8
Pipe-Exhaust
Gasket-ex. Manifold
Washer - Spring M8
Scrw-Hex M8 x
Cap-Radiatator
Screw - Cap Head M8 x 40
Battery Brace
Bracket - Bug Screen LH
Fan Shroud Plate
960 FRONTLINE
PARTS MANUAL
LIST OF PARTS
QTY
REMARKS
1
2
1
1
1
1
1
1
3
1
1
(Perkins Number 135997030)
4
4
1
5
2
Secures Battery
1
1
Parts-49
